Saturno Models

Saturno Turismo (1947-1951)

Engine Type: single cylinder 4 stroke
Power / rpm: 18 hp @ 4,500 rpm
Max Speed: 120 km/h
Displacement: 498.46 cm
Bore & stroke: 84 X 90 mm
Cast iron cylinder & cylinder head
Valve Angle: 90 Degrees
Valve Diameter: 38 / 38 mm
Compression Ratio: 5.5:1
Carburetor: Dellorto 28mm
Transmission: 4 Speed
Front Suspension: parallelogram
Rear Suspension:  horizontal springs enclosed in frame with adjustable dampers
Front Brake: 220 mm side drum
Rear Brake: 185 mm side drum
Front Tire: 3.25 X 19"
Rear Tire: 3.25 X 19"
Dry weight 168 kg

Saturno Militare (1947 - 1958)

Engine Type: single cylinder 4 stroke
Power / rpm: 19 hp @ 4,500 rpm
Max Speed: 120 km/h
Displacement: 498.46 cm
Bore & stroke: 84 X 90 mm
Cast iron cylinder & aluminum cylinder head
Valve Angle: 90 Degrees
Valve Diameter: 38 / 38 mm
Compression Ratio: 5.5:1
Carburetor: Dellorto 28mm
Transmission: 4 Speed
Front Suspension: parallelogram (1947 - 1950)
Telescopic  Front Suspension (1951-1958)
Rear Suspension:  horizontal springs enclosed in
frame with friction dampers (1947 - 1950)
Telescopic Rear Suspension (1951-1958)
Front Brake: 220 mm side drum (1947 - 1950)
Central Front Brake: (1951-1958)
Rear Brake: 185 mm side drum
Front Tire: 3.50 X 19"
Rear Tire: 3.50 X 19"
Dry weight 182 kg
